Socket for Single In-line 5253-100-5 5250/5253W-100-7T for your Package

Azimuth Electronics makes Sockets for Single In-line 5 Leads @ .100 c/c 5253-100-5 5250/5253W-100-7T for your Package . We can make custom sockets for your package. Socket Manufacturer Delivering the Highest Quality Quad Flat Packages, Worldwide. From Design to Prototype to Production, We Welcome the Challenges and Opportunities We Face From Ongoing Technological Advancements.

Single In-line 5 Leads @ .100 c/c

Design Features:
• Efficient size provides high burn in board density.
• Cantilever thru-hole wiping action contacts.
• Operates at temperatures from -55°C to +155°C.
• Accommodates packages with straight leads up to .023" wide x .012" thick
and .150" min. long.
• Mounts with two #2-56 round head screws.
Available on G-10 (FR-4) mounting boards or custom printed circuit boards.
• Use two or more sockets for packages with leads on two or more sides.
• Repairable. Replacement components available.

Specifications:
• Insulator: Polyphenylene Sulfide (PPS)
• Contact: Beryllium Copper (BeCu), spring temper.
Plating: 30μ inches gold over 30μ inches nickel.
• Current carrying capacity up to 10 amps pulsed, 4 amps continuous
